Technical Data
Model | BFC 6120KD Low Floor City Bus |
General Data | |
Dimension | 12000*2550*3210 |
Kerb Weight (kg) | 11600kg |
Gross Vehicle Weight (kg) | 15600kg |
Seat Capacity | 20-24+70 |
Fuel Tank Capacity (L) | 200L |
Driveline system | |
Engine | Six cylinders in line，turbocharged |
Clutch | Sachs MF430 |
Gearbox | QJ S6-90,6 shifts |
Front Axle | ZF front axle,low floor |
Rear Axle | Local,Drum brake |
Suspension System | Front suspension: Independent air suspension 2 air bellows +2 shock absorbers Rear suspension: Neoplan A-type beam+4 air bellows+4 shock absorbers |
Steering System | power steering |
Braking System | Front disc brake and rear drum brake (automatic clearance adjustment) ABS |
Body + Interior Fitting+ Electrical System | |
Body structure | Germany Neoplan Technology Monocuque |
Doors | Aluminum, Pneumatic- controlled ,Front and middle |
A/C | Dependent overhead air conditioner with the cooling capacity of ≥32000kcal/h |
Dashboard | Luxury Dashboard |
Electrical System | 24V |
video system | Hard disc player+Radio+Destination Indicator |
